Name:Nitrogen SMD Reflow Oven Lyra733
Model:SMD Reflow Oven
Brief:

A reflow oven, reflow soldering oven, SMT reflow oven, PCB oven is a machine primarily used to reflow surface mount electronic components onto a printed circuit board (PCB).

Content

Nitrogen SMD Reflow Oven 10 Zones

Reflow Oven

Reflow Oven

SMT Oven

❙ Introduce of SMT Reflow Oven

A reflow oven, reflow soldering oven, SMT reflow oven, PCB oven is a machine primarily used to reflow surface mount electronic components onto a printed circuit board (PCB).

1. Control System

Computer or Instrument control, make sure machine working steadily.

2. Hot Air Heating System

Both top and bottom zones hot air heating,good heater compensatory,High thermal efficiency,energy saving,speedy heating,suitable for soldering components like BGA,CSP etc.Special forced hot air circulation structure makes PCB and components heat evenly, Temperature Accuracy ± 1.5 °C, room temperature settling time less than 20 minutes.

3. Cooling System

Independent cooling area ensures the low temperature when PCB comes out.

4. Transmission system

Use imported motors, speed adjuster, smoothly running, adjustable speed at 0-2000mm/min.

❙ Specification of SMT Reflow Oven

Model Lyra 622 Lyra733
Dimension (L*W*H)mm 5040x1450x1450 5800x1450x1450
Machine Weight Approx. 2200KG Approx. 2400KG
Number Of Heating Zones Up8/Bottom8 Up10/Bottom10
Length Of Heating Zones 3030mm 3730mm
 Number of Cooling Zones 2 3
Control System PLC+Computer PLC+Computer
Transmission Agent Chain + Mesh Chain + Mesh
Max.Width Of PCB 460mm 460mm
Power For Warm Up 45kw 55kw
Power Consumption 8kw 10kw
Conveyor Height 900+/-20mm 900+/-20mm
Model A600 A600D A800 A800D
Dimension (L*W*H)mm 3400x800x1350 4150x850x1350
Weight Approx.739KG Approx.850KG
Number Of Heating Zones Top6/Bottom6 Top8/Bottom8
Length Of Heating Zones 2300mm 2600mm
Power For Warm Up 12kw 15kw
Power Consumption 5kw 6kw
Transmission Agent Mesh Mesh+Rail Mesh Mesh+Rail
Fixed Rail Side N/A Front (Option:Rear) N/A Front (Option:Rear)
Control System Instrument PLC+Computer Instrument PLC+Computer

❙ ETA Customer Factory

▽  Saudi Arabia - Semi auto LED production line

SMT Reflow Oven

▽  Russia customer - Full SMT production line

Reflow Soldering Oven

▽  Poland customer (Battery Chargers and Adapters) - Full SMT production line

Reflow Oven

▽ Customized reflow soldering oven for HUAWEI (5G products) Shenzhen, Qingdao, Dongguan, Wuhan factory.

Reflow Oven

❙ Company Profile

Reflow oven

ETA is the SMT machine supplier with professional 25-year-experienced sales and after sales team, providing SMT solutions including pick and place machine, SMT reflow oven, SMT stencil printer, SMT line and wave soldering machine.
We also is the partner of JUKI pick and place machine and Hanwha/Samsung pick and place machine, can provide the best SMT technical services and accessories support for JUKI, HANWHA/SAMSUNG, YAMAHA, PANASONIC brands.

Successful Experience:

Eta's Customer In 35 Countries Around the World

1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.

2. Training More Than 500 Experts and Technician for Customers.

3. Became the Most Reliable Chinese Partner for You.

For SMT Factory Setup, We Can Do for You:

1.  We Provide Full SMT Solution for You

2.  We Provide Core Technology With Our Equipments

3.  We Provide The Most Professional Tech Service

4.  We Have Wealthy Experience on SMT Factory Setup

5.  We Can Solve Any Question About SMT

❙ ETA SMT Machine Exhibition

Reflow oven

SMT Reflow Oven

❙ SMT Reflow Oven Certificate

ETA Products Certificate

❙ ETA Global Service

ETA Global Service

❙ Customers' Feedback

❙ FAQ

Q: What we can do for you?
A: Total SMT Machines and Solution, professional Technical Support and Service.

Q:Are you a trade company or a manufacturer?
A: OEM & ODM service are available.

Q: What is your delivery date?
A: The delivery date is about 35 days after receipt of payment.

Q: What is your payment terms?
A: 30% deposit in advance and 70% balance before shipment.

Q: What your main customers?
A: Huawei,Foxconn,Vtech,Sumida,Kemet,Vishay,Bosch,Canon.

Q:  Why choose us?
A: Leading SMT Supplier in China; Trade assurance to USD 560,000+; Professional after-sales service team.
❙ Packaging
Reflow Oven



If you could not find any similar items you want, you may send some photos to us. because our catalog and website haven't included all of our products.

❙ SMT Reflow Oven Video
